CAM130

4K Conference Camera

Awards & Certifications

4K Camera with Intelligent Lighting for Small Rooms and WFH

The CAM130 is a 4K camera with intelligent lighting for use in small rooms and WFH. Embedded auto and preset framing can follow and capture meeting participants even when they’re wearing masks, saving time and enhancing meeting efficiency. Also, a built-in lens cover is designed to protect your privacy from hackers, and flexible mounts fit diverse usage scenarios. All that innovation adds up to brighter and better conferences.

Professional 4K Camera Offers Lifelike Imaging

The CAM130 demonstrates vivid imaging even in complex light conditions with a 4K True WDR Sony Sensor. Equipped with high-performance imaging functions like auto exposure, white balance, backlight compensation, and dual-lens viewing angles (120° /90° ) for different using scenarios, the CAM130 makes a strong case for use in huddle room and WFH scenarios.

AverCAM130

Typical Cam

Intelligent Lighting Automatically Adjusts to Fit Light Conditions

Establish an energetic and professional image in virtual meetings. When you’re working from home in a dim room, the camera offers full-range color temperature and automatic lighting level adjustments. The CAM130 ensures that you look great in any light.

Without Light

With Light

Lens Cover Secures Privacy in a Virtual World

Privacy matters! The CAM130 values your privacy with a built-in lens cover. No need to worry about network hackers anymore. Simply cover the lens to block the camera and keep personal information secure.

Auto Framing That’s Easy to Use

Effortlessly conduct meetings with auto and preset framing. With the innovative SmartFrame function, the CAM130 smoothly follows and frames all participants on screen or a specific area. Highly improve meeting efficiency and create a quality conference experience.

Front

Side

Front

Side

SEE all specs

Display
Screen Size
55″

Resolution
3840×2160(16:9)

Brightness
350nits

Contrast Ratio (Typical)
4000:1

Operation Hours
16/7

Color Gamut
92% (DCI-P3, CIE 1976)

Haze
2%

Brightness (Typ.)
350 nit

Pixel Pitch (mm)
0.315 x 0.315

Diagonal Size
55

Measured
54.6″ / 138.7cm

Type
VA

Orientation
Landscape / Portrait

Active Display Area
1209.6(H) x 680.4(V)

Connectivity
External Control
RS232C (in/out), RJ45

Video Input
HDMI 2.0 (3)

USB Input
USB 2.0 x 2

Audio Output
Stereo mini Jack

Power
Power Supply
AC 100 – 240 V, 50/60 Hz

Power Consumption (Sleep Mode)
less than 0.5W

Power
Consumption
(Max[W/h])
143

Power Consumption
(Typical[W/h])
96

Audio Out
Stereo Mini Jack

RS232 In
Yes

RS232 Out
Yes

Features
Key
UHD Signage with
Built-in MagicInfo S10,
SSSP
10.0

Special H/W
Symmetric Design
(same with QxR)
Center IR Temperature Sensor

Special S/W
Workspace
(Microsoft365/VMWare/RDP)
Custom Home
Auto Source Switching &
Recovery
Dicom Simulation Mode
Director Mode
SmartView+(PC)
Upgradable Web-Engine
Tizen Enterprise Platform
SmartView+(mobile)
Video Conference Solution
[end of June~]
Smart Calibration

12/7 Operation
Yes

Internal Player
Processor
1.7GHz Quad-Core CPU

Operating System
Tizen 6.5

Storage (FDM)
8GB

Dimensions
Packaging (W x H x D)
1402 x 858 x 163

Set Dimensions (mm)
1235.1 x 707.9 x 46.3

Weight
Package Weight
23.6

Set Weight
18.1

Accessories
Included in Box
Quick Setup Guide,
Warranty Card,
Power Cord
RS232C(IN) Gender
Remote Controller & Batteries

Optional Stand
STN-L4355G

Specialty
CML400XR

Optional Mount
WMN4070SG (Land Only)
WMN750ME

Mechanical Specs
VESA Mount
200 X 200

Bezel Width (Top/Side/Bot)
(mm)
9.2mm(U/L/R), 11.2mm(B)

VESA Mount Screw
(Min~Max) M8, 29~30

Bezel Width (mm)
9.2mm(U/L/R), 11.2mm(B)

Sound Speaker
Type 10W 2ch

Operation Conditions
Temperature
0℃~ 40℃

Humidity
10~80%

Certification
Safety
60950-1 / 62368-1

EMC
Class B

Environment ENERGY
STAR 8.0, EPEAT

IP Rating
IP5x

Security
802.1x(WPA2 Enterprise) :
EAP-TLS, EAP-TTLS, EAP-PEAP

SEE all specs

Camera

4K optical lens, 120° FOV, up to 5X zoom via ePTZ*

- Sony 4K sensor: ultra-crystal-clear image in any lighting
- Frame rates: (16:9) 4K 30fps ; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
- Intelligent fill light: automatically adjusts lighting levels to make you look energetic in a dim environment**
- SmartFrame: automatically adjusts FOV (auto focus) to track and fit all participants onscreen
- Innovative Preset Framing: Follows the presenter through preset areas
- True WDR up to 120db: 3D noise-reduction and superb backlight compensation optimize lighting in high-contrast conditions
- Mirror, flip, AE, white balance: auto/manual override via PTZApp2
- Minimum focus distance: 60 cm
- People-counting API: enterprises and third-party software providers can obtain people-counting data for better understanding of meeting-space usage
- 10 camera presets (through remote control and IP web page)
- Standard tripod screw holes

Microphone

2 omnidirectional microphones
Frequency response: 100–12K Hz
Sensitivity: -37 dB
Echo cancellation and background noise suppression

Connectivity

USB type-C 3.1 connector, backward compatible with USB 2.0
DC jack for power adapter (for USB 2.0 connection while using fill-light function)

Video Format

YUV, YUY2, MJPEG
H.264 (UVC 1.5)

USB

3.1 Gen 1, backward compatible with USB 2.0
UVC 1.1 (USB video), UAC 1.0 (USB audio), UVC1.5*

Security and Mount

Built-in TV clip
Kensington slot
1/4′ tripod mounting screw

Control

IR remote control (optional accessory, compatible with CAM540)
UVC / plug-and play
PTZApp

System Requirement*

Windows 7/10/11
MacOS 10.14 or higher
Chromebox 3 version 94.0.4606.114 or later

Hardware Spec*
2.4GHz Intel® Core 2 Duo processor
2GB RAM or more
USB 3.1 Gen1 port

Hardware Spec*

3.2 GHz Intel® Core™ i5-4460 processor
4 GB RAM or more
USB 3.1 port, backward compatible with USB 2.0

Power supply

AC 100V–240V, 50/60 Hz
5V/2A

Environment Data
Operation temperature: 0 to 40°C
Operation humidity: 20% to 80%
Storage temperature: -20 to 60°C
Storage humidity: 20% to 80%

Dimension

Package dimensions: 217(L)*155(W)*118(H) mm
Package weight: 0.729 kg
Camera: 160 (L) x 37 (H) x 60 (D) mm/ 0.282kg
Remote control: 149.72 x 42.3 x 19.29 mm/50g (optional item)

Package contents

CAM130 unit
Power adapter (10 ft/3 m)
USB 3.1 type-C to type-A cable (6 ft/1.8 m)
QR code card
Tripod screw

Optional Accessories

Remote control (also compatible with VB130)
USB 2.0 type-C to type-A cable (15 ft/5 m)
USB 3.1 Extension Cable (10 m/20 m/30 m)

Warranty

Camera: 3 years
Accessories: 1 year

Compatible Applications

Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans, Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
